Guide Rail .

Ekifo we bava:Hebei, China .

Waranti:Omwaka1 .

Obuwagizi obukoleddwa ku bubwe:OEM, ODM, OBM

Erinnya ly’ekintu:Storan .

Ennamba y’omulembe:2008

Ebikozesebwa:HT200-HT300 .

Obutuufu:Customized .

Enkola y’okukola:Emikono .

Obuzito bw’ekintu:Customized .

Obusobozi:Customized .

Specification:1500-4000mm mu buwanvu oba customize

Surface:T-slots .

Obukaluba bw’ekifo ekikola:HB160-240 .

Okujjanjaba kungulu:Okukola ebyuma .

Enkola y’okufumbisa:Resin Sand Casting .

Okusiiga ebifaananyi:Primer ne Face Painting .

Surface coating:Okulonda amafuta ne pulasitiika oba okubikkibwako langi eziyiza okukulukuta .

Precision Grade:2-3.

Ebbugumu ly’okukola:(20±5.) ℃

Okupakinga:Plywood Box .

Obudde bw’okukulembera .

Ekyuma ekisuuliddwa T-groove Ebintu ebiva ku ttaka nabyo bimanyiddwa nga: eggaali y’omukka ey’oku ttaka, eggaali y’omukka ey’oku ttaka eya T-groove, ekitangaala eky’oku ttaka, ekyuma ekikuba ebyuma ku ttaka, ekyuma ekikuba ebyuma, ekyuma ekimu ekya T-groove, eggaali y’omukka ey’oku ttaka ey’ekyuma ekisuuliddwa.
Ekigendererwa ekikulu eky’eggaali y’omukka ey’oku ttaka ey’ekyuma ekisuuliddwa kwe kugikola n’okugikuŋŋaanya mu kifo ekisuuliddwa nga kyesigamiziddwa ku bifo ebinywevu eby’ebyuma. Okusinga ekozesebwa mu kugatta, okugezesa, okuweta, n’okukebera ebyuma ebinene.

Ebintu Ebirungi Ebirungi Eby’ekyuma Ekisuuliddwa T-groove Ground Rails .:
Ebirungi ebiri mu kyuma ekisuuliddwa t-groove ground rails: nga okozesa ebyuma ebisuuliddwa ku ttaka, tekikwetaagisa kubifuula bifo binene, ekikekkereza ssente z’ebintu n’okukwata ekifo ekitono, ekivaamu okusaasaanya ssente ennyingi.

Ekintu eky’ekyuma ekisuuliddwa t-groove ground rail kibeera kya maanyi nnyo nga kirimu ekyuma ekisuuliddwa HT200-250, nga kirimu obugumu obukola ku ngulu kwa HB170-240. Okusuula kuno kufunye lawundi bbiri ez’okusengejja okw’ekikugu ku 600 °C -700 °C oba okukaddiwa okw’obutonde okumala emyaka 2-3 okuggyawo ddala situleesi ey’omunda, nga n’obutuufu obutebenkevu n’okuziyiza okwambala obulungi.

resin sand casting: Engeri okukola eggaali y’omukka mu biragiro gye kikakasa okutebenkera .

Precision mu linear guide rails etandika n’okukola excellence. Storaen ekozesa advanced resin sand casting okukola yinginiya w’ebigoma ebizitowa linear guide rails ezituusa obutebenkevu obutakwatagana ku by’ennyonyi, mmotoka, n’okukozesa amakolero amazito. Laba engeri enkola yaffe gy’ekakasaamu okwesigika n’okukola mu bika by’eggaali y’omukka byonna ebilungamya .:

1. Ebintu ebirungi: HT200-HT300 cast iron olw’obwetaavu bw’amakolero

Okusuula omusenyu gwa resin kutandika n’okulonda ekyuma ekisuuliddwa eky’enzirugavu ekya HT200-HT300 (160–240hb hardness), ekirondeddwa ku:

Amaanyi agatebenkedde: Amaanyi g’okusika kwa 200–300mPa gawagira ttani 5–50 ez’ebikozesebwa ebitambula, ebirungi ennyo ku gaali z’omukka ezilungamya linear ezikola emirimu egy’amaanyi.
Okuziyiza situleesi: Ensengeka y’empeke ey’enjawulo ekendeeza ku situleesi ey’omunda ebitundu 40% okusinziira ku kusuula omusenyu ogwa kiragala, okukendeeza ku kuwuguka mu mbeera za 10°C–40°C olw’omutindo gw’eggaali z’omukka ezilungamya ebyuma ezikwatagana.

2. Okubumba obulungi (precision molding) ku geometry ezitali zimu .

Omusenyu gwa resin ogw’okwekakanyala gusobozesa ebika by’eggaali y’omukka ebilungamya ebizibu ennyo nga biriko okugumiikiriza okunywevu .:

CNC-pattern accuracy: T-slot dimensions (14–36mm obugazi, 8–20mm obuziba) etuukiddwako ne ±0.1mm precision okugatta okutaliimu buzibu n’enkola z’okwekolako.
Core Stability: Internal cores zikuuma 0.05mm/m straightness, okuziyiza obulema n’okukakasa class 2–3 flatness (≤0.02mm/m for 2000mm rails)—critical for precision alignment.

3. Okulongoosa mu bbugumu okusobola okuwangaala & okutebenkera .

Enkola ey’emitendera 3 eyongera ku mutindo gw’eggaali y’omukka .:

Okuwummuza ku situleesi (550°C/4H): Emalawo ebitundu 90% eby’okunyigirizibwa kw’okusuula okuziyiza okukyukakyuka mu kiseera ky’okukola ebyuma/okutambuza.
Normalizing: Erongoosa ensengeka y’empeke okumala 2x obuwanvu bw’okwambala obuwanvu mu kukozesa enzirukanya ennene (10,000+ load cycles).
Okusenya ku ngulu: Okumaliriza okutuuka ku RA ≤1.6μm okusobola okutambula obulungi n’okusikagana okutono mu nkola ez’otoma.

4. Obusobozi bw’okuzitowa & load obusobola okulongoosebwa .

Storaen akwatagana ne byonna ebyetaago by’eggaali y’omukka ebilungamya n’obwetaavu bw’omugugu .:

Standard range: obuwanvu bwa 1500–4000mm, 200–500mm obugazi okukozesebwa bulijjo; custom sizes okutuuka ku 6000mm ku byuma ebinene ennyo.
Enteekateeka ennywevu: Enzimba y’omukutu gwongera ku busobozi bw’okutikka ebitundu 30% (okutuuka ku ttani 80/m) awatali buzito obwongezeddwa, ekirungi ennyo mu kukuŋŋaanya eby’omu bbanga nga kyetaagisa obutuufu n’okutambula.

5. Enkizo ya Storaen ey’okusuula .

Obumanyirivu mu kukola ebintu bingi: Efulumya ebika by’eggaali y’omukka byonna ebilungamya —okuva ku gaali z’omukka ezizitowa ennyo okutuuka ku bikolwa eby’emirimu eminene egy’amaanyi —n’obutuufu obwenkanankana.
Okukakasa omutindo: Okugezesa 3D laser scanning/CMM kukakasa nti okugoberera GB/T 1958-2017/ISO 1101, nga kuwagirwa warranty ya mwaka 1 ku dimensional drift.
Obulung’amu: Obusobozi bwa 500pcs/olunaku butuusa eggaali y’omukka eya mutindo mu nnaku 7, eby’okugonjoola eby’ennono mu wiiki 4–6—okutebenkeza sipiidi n’obutebenkevu.

Okutebenkera mu linear guide rails kwa yinginiya, si kwa butanwa. Storaen’s resin sand casting egatta ebintu eby’omutindo, okubumba obulungi, n’okulongoosa ebbugumu okukakali okutuusa emirimu egy’amaanyi egy’okulungamya linear guide n’ebyuma ebilungamya ebyuma ebituukiriza ebyetaago by’amakolero ebisinga okukaluba. Yeekenneenya ebika by’eggaali y’omukka ebikulembeza leero era olabe enjawulo mu kukola ebintu eby’omulembe mu kukola ebyuma n’okuwangaala.

Engeri Guide Rails gye zikyusaamu ebyuma ebisuuliddwa kungulu ku ngulu okusobola okukekkereza ku nsimbi .

Ebyuma eby’ennono ebisuuliddwa kungulu bifuga okukuŋŋaanya n’okukeberebwa mu makolero, naye obunene bwazo, obunene obutakyukakyuka, n’ebisale by’okuddaabiriza eby’amaanyi bisomooza obulungi bw’okukola. Storaen ayanjula linear guide rails nga eky’okuddako ekitali kya ssente, okutuusa precision, okukyukakyuka, n’okutuuka ku 30% omugatte gw’okukekkereza ku nsaasaanya bw’ogeraageranya ne plates eza bulijjo. Laba engeri ebika by’eggaali y’omukka ebyaffe eby’omulagirizi gye biddamu okunnyonnyola amakolero workholding .:

1. Dizayini ekekereza ekifo: Okukendeeza ku bigere 50% .

Cast iron plates (okugeza, 2000x1500mm) zeetaaga ekifo ekinene wansi n’emisingi emizito, naye Storaen’s heavy-duty linear guide rails offer modular, streamlined solutions:

Vertical & horizontal flexibility: vertical guide rails (okugeza, 1500mm height models) ziteeka mu vertikal ku bisenge oba mu bifo, okukola ebifo eby’okukoleramu eby’okukuŋŋaanya ebya 3D awatali kusaddaaka kitundu kya wansi —ekirungi eri obutoffaali bwa roboti obutono oba ebifo eby’okuweta eby’otoma.
Obuwanvu obusobola okulongoosebwa: Obunene bw’eggaali y’omukka obulagirizi bwa mutindo buva ku mm 1000–4000, nga zirina okuyungibwa okutaliimu buzibu okukozesebwa ennyo (okutuuka ku mm 6000), ekikendeeza ku kasasiro w’ebintu ebitundu 40% okusinziira ku bipande by’ekyuma ekisuuliddwa okutuuka ku sayizi.

2. Obutuufu obutasaasaanya ssente nnyingi awatali kukkaanya .

ate ebyuma ebisuuliddwa bituuka ku kiraasi 2 flatness (≤0.02mm/m), Storaen’s ground-finish linear guide rails zikwatagana n’obutuufu buno ku 30% wansi guide rail price:

Okukozesa obulungi ebintu: HT200 Cast Iron Construction (180HB Hardness) ekozesa ebintu ebitono ebitundu 25% okusinga obupande obugumu obw’okungulu ate nga zikuuma obusobozi bwa ttani 50/m, okutebenkeza obukakanyavu n’ebyenfuna.
Okukendeeza ku ndabirira: Amafuta agaziyiza okukulukuta (5μm thickness) gakuuma okunyogoza n’obunnyogovu, okugaziya obulamu bw’obuweereza 2X bw’ogeraageranya n’ebipande ebitasiigiddwako langi ebyetaagisa okuddamu okukola buli mwaka (omuwendo gwa doola 5,000+ ku bipande ebinene).

3. Okutuukagana n’enkola y’emirimu egy’amaanyi .

Fixed cast iron plates strugget with changing production needs, naye ebika by’eggaali y’omukka ebiragiro bisukkulumye ku bintu mu ngeri nnyingi .:

Modular T-slot Design: 14–36mm obugazi (±0.1mm tolerance) bakkiriza ebikwaso ebifulumya amangu, emikono gya roboti, oba ebikozesebwa mu kupima, ekisobozesa okuddamu okusengeka ebinyweza eddakiika 5 okusinziira ku ssaawa 2+ ku nteekateeka ezisinziira ku pulati.
Omutindo gw’emirimu egy’amaanyi: Eggaali y’omukka ey’omutawaana (80 tons/m load capacity) enyweza ebyuma ebinene ng’ebitundu by’okunyiga sitampu oba ebitundu by’ennyonyi eby’omu bbanga, okukyusa enkuŋŋaana za pulati eziwera n’enkola z’eggaali y’omukka emu ezinyanguyiza okukwatagana.

4. Storaen’s value proposition: okusinga okukekkereza ku nsaasaanya yokka .

Okuteeka mu nkola amangu: Eggaali y’omukka eyakolebwa nga tebannaba kukola mmeeri nga yeetegefu okuteekebwa, okusala ku budde bw’okuteekawo ebitundu 60% bw’ogeraageranya n’okuleega n’okunyweza ebyuma ebisuuliddwa.
Custom Solutions: Need anti-magnetic coatings for electronics assembly oba oversized guide rail size for wind turbine manufacturing? Ttiimu yaffe eya OEM etuwa eggaali y’omukka etunuuliddwa mu wiiki 4–6, nga tewali ssente za order ezisinga obutono.
Okukakasa omutindo: Buli ggaali y’omukka etuukiriza GB/T 1958-2017 Geometric Tolerances era erimu ggaranti y’omwaka 1 —okumalawo akabi akali mu kuteeka ssente mu nkola endala ez’okukola embalirira.

5. Okusaba nga okukekkereza ku nsaasaanya kutuukiriza omulimu .

Automotive Assembly: Kyuusa 3m2 cast iron plates ne 2000mm ezikola linear guide rails bbiri ezikola emirimu egy’amaanyi, nga zikekkereza $10,000 mu upfront costs ne 20% floor space for engine block alignment.
Aerospace tooling: lightweight linear guide rails (30% ziweweevu okusinga empulati eziringa ezenkanankana) zikendeeza ku mugugu gwa crane mu kiseera ky’okukebera ebitundu by’ebiwaawaatiro, okukendeeza ku nsaasaanya y’amasoboza ag’emirimu.
General Machining: Portable Guide rail types (50–100kg weight) Okumalawo obwetaavu bw’okuteekebwako pulati ez’olubeerera, ezisinga obulungi eri amaduuka g’emirimu agatera okuddamu okusengeka ebyuma.

Toleka bipande bya kyuma ebisuuliddwa ku mulembe bifulumya embalirira yo n’ekifo kyo wansi. Storaen’s Linear Guide Rails zituusa obutuufu bwe weetaaga ku katundu k’omuwendo, nga modularity to future-proof of your operations. Okuva ku mudumu gwa linear guide rails for industrial giants okutuuka ku customizable guide rail types for niche applications, tuddamu okunnyonnyola omuwendo mu workholding solutions. Yeekenneenya enkola yaffe ey’emiwendo gy’eggaali y’omukka ey’okuvuganya leero era otandike okutereka nga tosaddaase mutindo.

•
• Ekifaananyi Ekiwandiiko Ennyonnyola 1 .
•
•

Ennyonyola n’ekyokulabirako (obuwanvu x obugazi x obuwanvu) (Ekitundu: mm .)

1500 x 150 x 150 1500 x 200 x 150 1500 x 250 x 300 1500 x 300 x 400 .

2000 x 200 x 300 2000 x 250 x 300 2000 x 300 x 350 2000 x 350 x 350 .

2500 x 200 x 300 2500 x 250 x 300 2500 x 300 x 350 2500 x 300 x 400 .

2750 x 200 x 300 2750 x 250 x 300 2750 x 300 x 350 2750 x 300 x 400 .

3000 * 300 * 300 3000 * 300 * 350 3000 * 300 * 400 3000 * 320 * 400

3200 * 300 * 300 3200 * 300 * 350 3200 * 300 * 400 3200 * 320 * 400

3500 * 300 * 300 3500 * 300 * 350 3500 * 300 * 400 3500 * 320 * 400

4000 x 300 x 300 4000 x 300 x 350 3500 x 300 x 400 4000 x 320 x 400 .

4500 x 300 x 350 4500 x 300 x 400 4500 x 320 x 400 4500 x 350 x 400

5000 x 300 x 400 5000 x 350 x 400 5000 x 400 x 450

Eby’ekikugu ebikwata ku kyuma ekisuuliddwa T-slot wansi Guide Rail .:
